UPTUP300ACT

UP300AC Touch 300W Multi- Chemistry AC/DC Charger

The UP300AC is a high-powered, single channel charger capable of charging a 6S pack at 20A. Features include: Easy-to-use touch screen, selectable charge termination voltage, adjustable delta-peak (NiCd/NiMH), individual cell balancing, LiHV mode, internal resistance monitoring, battery meter function, data storage (10 profiles in memory), a USB port for firmware upgrades, and a USB power port for charging phones and tablets. Covered by Ultra Power's unconditional 1-year exchange guarantee.

Specifications:

• Input voltage: AC 100-240V / DC 11.0-18.0V
• Charge power: Max. 300W
• Discharge power: Max. 25W
• Charge current range: 0.1 - 20.0A
• Discharge current range: 0.1 - 5.0A
• LiIo/LiPo/LiFe/LiHv cell count: 1 - 6S
• NiCd/NiMH battery cell count: 1 - 15 cells
• Pb battery voltage: 2V~20V (1 - 10 cells)
• Battery data memory: 6 profiles

Product Manual
