DXS Transmitter Only
Item No.
Spektrum - SPMR1010
For any RC flight enthusiast looking to strike the perfect balance between economy and innovative, high-end features the 7-channel Spektrum™ DXS radio can combine with a DMSX receiver of your choice to create the ideal system. It offers full range control, secure DSMX® interference resistance, advanced telemetry capabilities, and proven transmitter ergonomics for fatigue-free flying. The simplified setup of the DXS also gets you into the air faster, with less time needed for preparation and programming.
The DXS transmitter is built around proven Spektrum™ DSMX® 2.4GHz frequency-agile technology — the most advanced spread spectrum RC technology to date. By adding the agility of unique frequency shifts to the superior interference resistance of a wideband signal, and by limiting those shifts to a smaller portion of the 2.4GHz band, DSMX transmitters provide on-channel interference protection that's second to none.
Weight distribution, switch placement and trim switch positions have been optimized for comfort and fatigue-free control. An integrated handle and neck strap hook are included for easy carrying. Ports are provided in the rear battery compartment for using optional wireless trainer and data port. The SRXL2™ DSMX® Remote Receiver (available separately) is required for wireless trainer support. Registration and firmware updating are possible from your PC by downloading the software from the DXS product page at SpektrumRC.com and using the USB Programming Cable (available separately).
Get essential flight battery status information at a glance from the DXS transmitter when using it with Smart Avian™ ESCs and Smart LiPo batteries (sold separately). Four green LEDs on the front of the transmitter communicate the flight battery voltage level. In normal operation with a Smart ESC and Smart battery, only one of the LEDs will glow if the battery is low. Two illuminate to indicate a half-charged battery, three light if the battery is between half and full charge, and all four shine when the flight battery is fully charged.
Receiver | Sold Separately |
Telemetry | Yes |
WiFi | No |
Left / Right Hand Operation | No |
Modes | Mode 2 |
Touchscreen | No |
Bind Method | Bind Button |
Operating System | Not Applicable |
Range | Full |
Gimbal Type | Potentionometer with bushing |
Programmable | No |
Serial Port | No |
Technology | SAFE |
Type | Aircraft radio |
Color Screen | No |
Frame Rate | 22ms, 11ms |
Modulation | DSMX |
Application | Aircraft |
Transmitter (Tx) Battery Type | 4 AA alkaline |
Water-Resistant | No |
Channels | 7 |
Audio | None |
Band | 2.4GHz |
Completion Level | Transmitter Only |
